PNP NO+NC 2mm Gap Electric Label Sensor 24V DC Packing Machine Usage

Brand Name : F*C

Model Number : FC-2100P

Certification : CE,Rohs

Place of Origin : China

MOQ : 1pcs

Price : USD25-38 per pieces

Payment Terms : TT

Supply Ability : 50pcs per week

Delivery Time : 7-10days

Packaging Details : single box package

Power supply : 12-24V DC

Output type : PNP NO. NC

Acuracy : 0.5mm

Slot width : 2mm

Application : Packing Machine

Cable length : standard 2m cable

Load current : 100mA at 24VDC

Response time : 500us MAX

Contact Now

PNP NO+NC 2mm Gap Electric Label Sensor 24V DC Packing Machine Usage

Specifications for sticker Label sensor:


Model	FC-2100P
Output type	PNP NO NC
Detection distance	2mm
Light source	940nm infrared modulated light
Operating voltage	DC12-24V±10%
Current consumption	15mA Max
Load current	100mA Max at DC ;24V
Protection circuit	Reverse polarity protection and short circuit protection
Response time	500us Max
Leakage current	<0.01mA no-load
Operating temperature	-10℃-+50℃(without icing or condensation)
Storage temperarure	-20℃~+60℃(No freezing )
Ambient humidity	35%-85% RH
Protection degree	IP66
Meterial	Aluminium metal sheet
Wiring method	φ4mm×2M/4-wires/φ4mm×2M/M8 4-wires

PNP NO+NC 2mm Gap Electric Label Sensor 24V DC Packing Machine Usage

FAQ

Q:Are you sensors manufacturer?

A:Yes,over 30 years' experience in sensors field.We can make more profit for you.

our product has CE certificate.

Q:Can I get samples for test?

A:Yes,we;support free test samples and shipping cost at your side.

Q: What's your leadtime?

A:Generally speaking,we have stocks for 110 kind of different models and can ship at any time. If we don't have stock,our leadtime is 5-7 working days.;We will pull in the production schedule if your demand is urgently.

Q: What's your payment term?

A:You can pay us by T/T, Paypal, Westunion.

Q:How do you arrange the shipment ?

A:We normally ship by Fedex, UPS and TNT, we are VIP of this courier and get 60% discount. We also can accept other ship method if there is an need.

Application for sticker Label sensor:

Such Kind of label sensor is widely used in packing machine for normal adhesive label detection, any questions, just feel free to inquiry us.
